RBT Machinery Cutting Shape 6 Axis Cnc Milling Router With Double Worktable

The 6 axis cnc router，Truss-type rotary worktable, floor drain type dust collection device, in combination with high-performance dust collector, can collect external processing debris, which can meet the needs of closed workpiece processing.

Processing around the workpiece can achieve high-efficiency and high-precision processing results.
It can process a variety of composite materials, involving the processing of material components in multiple industries, with small errors.

Weight:	19500KG
Rated Power:	18.95-33.45KW
X/Y/Z axis travel:	330023001000MM
Size:	L7100W6615H4896MM
C/B Axis Travel:	±540°/±120°
Voltage:	3-380V
Control System:	Taiwan Syntec
Availability:

Quantity:



Inquire Add to Basket

Model:
RB-H5-3323-Z10
Brand:
RBT
Code:
8465990000

Product Description

Dual Table 5-Axis Rotary CNC Milling Machine for Automotive Manufacturing

Product Parameters:
The machine related parameters are as follows:

Content	Parameter	Content	Parameter
Name	Truss Type 5 axis CNC Machine	Brand	RBT
Model	RB-H5-3323-Z10	Voltage	3-380V
X/Y/Z Axis Travel	330023001000	Machine rated power	18.95KW~33.45KW
C/B Axis Travel	±540°/±130°	Weight	19500KG
Spindle power	3~20KW	Dimension	L7100W6615H4896mm
Control system	Taiwan*SYNTEC	Machine Origin	Guangdong / Fujian

Application Materials:

Composite materials:
including materials like carbon fiber (PCM, SMC, CFRTP such as PP/PC), carbon-carbon composites, and glass-reinforced plastics;

Plastics:
encompassing types such as ABS, PC, PP, PET, HDPE, and acrylic;

other materials:
Capable of processing high-density foams, woods, wood-simulated materials, stone, and additional non-metallic substances.

Rbt 5 Axis CNC Machine with High Performence Spindle for Plastic

Product certificates：

Company Team Appearance

Composite Material 5 Axis CNC Machine for Aerospace /Automotive/Medical Parts

COMPANY PROFILE

Fujian RBT Intelligent Co., Ltd. is an integrated intelligent equipment solution provider integrating R & D, manufacturing, sales and technical services, specializing in the customization of five-axis machining center manufacturers, engaged in this industry for more than 15 years. The main products are gantry type, truss type, fully enclosed 5/6 axis machining center, double head 5 axis, 6 axis machining center and all kinds of non-standard automatic intelligent production lines.

Cooperation customer representative

FAQ:

1. Dual Worktable Efficiency: The innovative dual worktable design enables continuous machining with one table cutting while the other prepares, enhancing workflow efficiency and facilitating safe, convenient loading/unloading with automated interaction between machining and material handling areas.

2. Precision Five-Axis Control: Capable of complex movements across five axes, this machine ensures precision and repeatability, handling complex geometries and multi-sided machining with ease. The advanced five-axis CNC system combines power, speed, and accuracy, with features like dust collection and RTCP for rapid, high-precision machining of difficult materials.

3. High-Performance Spindle: The machine is equipped with a high-torque spindle customizable for specific performance needs, ensuring optimal cutting performance on various materials. The Italian Hiteco twin-head spindle offers a 360° swivel angle for fast, high-precision operation.

4. Automatic Tool Management: An 8-tool capacity magazine and automatic tool changer reduce downtime and setup times, allowing seamless transitions between different tools during the machining process.
